Pressure transmitter WIKA A-10, 0...10 bar, G1/4A, 4-20mA, 2-L, 0 +80C

Pressure Transmitter WIKA A-10

The WIKA A-10 is a universal pressure transmitter for general industrial applications, offering outstanding reliability, precision, and durability.
It is designed for measuring pressure in gases, liquids, and oils, making it ideal for process control, hydraulic systems, and energy applications.

Key Features

• All-stainless steel design (316L) for both housing and wetted parts

• High accuracy: 0.5 % or 1.0 % of span

• Wide measuring range: 0...0.05 up to 0...1000 bar

• Multiple output signal options for flexible system integration

• Compact and robust for demanding environments

• Registered in the State Register of Measuring Instruments of Ukraine (No. U1959-15)

Technical Specifications

• Measuring ranges:
  0...0.05 to 0...1000 bar,
  0...0.1 to 0...25 bar abs.,
  −1…0 to −1…+24 bar

• Pressure type: gauge / absolute

• Accuracy: 0.5 % or 1.0 % of span

• Output signals:
  4–20 mA (2-wire),
  0–5 V, 0–10 V, 0.5–4.5 V, 1–5 V (3-wire)

• Response time: 4 ms

• Supply voltage: 8–30 V DC

• Material: stainless steel 316L

• Process connection: G 1/4 A DIN 3852-E

• Seal: NBR

• Electrical connection: angled connector DIN EN 175301-803 (Form A)

• Process temperature: 0…+80 °C (optional −30…+100 °C)

• Protection class: IP65

• Warranty: 12 months

• Manufacturer: WIKA (Germany)

Applications

• Industrial pressure control systems

• Hydraulic and pneumatic systems

• Mechanical engineering and energy industry

• Process equipment for liquids and gases

• Automation and monitoring systems

WIKA A-10 — a proven German-made pressure transmitter ensuring high precision, long service life, and stability across all industrial environments.
